84491550 - KIT DE SERVICIO - CASE CONSTRUCTION

This Kit includes the following parts:

• Part Number
  16043231
  Description
  PERNO.
  Quantity
  6
• Part Number
  190003888452
  Description
  TUERCA DE BLOQUEO.
  Quantity
  2
• Part Number
  198573C1
  Description
  BANDA DE SELLADO.
  Quantity
  1
• Part Number
  1994720C1
  Description
  KNOB.
  Quantity
  2
• Part Number
  232948A1
  Description
  A/C High-Pressure Switch - M10 x 1.25.
  Quantity
  1
• Part Number
  122579A1
  Description
  A/C Low-Pressure Switch - M10 x 1.25 x 229.
  Quantity
  1
• Part Number
  31-1081
  Description
  CLAMP.
  Quantity
  3
• Part Number
  86512165
  Description
  BOLT.
  Quantity
  3
• Part Number
  86528579
  Description
  Lock Nut.
  Quantity
  2
• Part Number
  87522595
  Description
  FUSE.
  Quantity
  1
• Part Number
  86588450
  Description
  Washer - 6.6 mm ID x 12 mm OD x 1.6 mm Thk.
  Quantity
  4
• Part Number
  81822758
  Description
  SCREW.
  Quantity
  2
• Part Number
  87528973
  Description
  BRACKET.
  Quantity
  1
• Part Number
  87529621
  Description
  Thermostatic Switch.
  Quantity
  1
• Part Number
  60-6318T91
  Description
  LOCK.
  Quantity
  1
• Part Number
  84373399
  Description
  A/C HOSE.
  Quantity
  1
• Part Number
  84373400
  Description
  Compressor-to-Condenser Hose Assembly.
  Quantity
  1
• Part Number
  86624185
  Description
  WASHER.
  Quantity
  3
• Part Number
  86625022
  Description
  HOSE CLAMP.
  Quantity
  2
• Part Number
  86625251
  Description
  Washer.
  Quantity
  6
• Part Number
  86633352
  Description
  Hose Clamp - Worm Gear - Stainless Steel - 57 mm-79 mm Dia.
  Quantity
  5
• Part Number
  86639000
  Description
  CLAMP.
  Quantity
  1
• Part Number
  86639038
  Description
  Bolt - Cl 10.9 - M6 x 25.
  Quantity
  2
• Part Number
  86639188
  Description
  Hex Bolt - Cl 10.9 - M6 x 40.
  Quantity
  2
• Part Number
  87577360
  Description
  SPRING CLIP.
  Quantity
  1
• Part Number
  87577361
  Description
  FOAM INSULATION.
  Quantity
  1
• Part Number
  86976974
  Description
  Grommet - 19 mm ID x 41 mm OD x 27 mm W.
  Quantity
  1
• Part Number
  86977693
  Description
  NUT.
  Quantity
  2
• Part Number
  84411602
  Description
  PLATE.
  Quantity
  1
• Part Number
  87587637
  Description
  PLASTIC-RUBBER TUBE.
  Quantity
  2
• Part Number
  832-10406
  Description
  SICHERUNGSMUTTER.
  Quantity
  2
• Part Number
  87016585
  Description
  U-Klammer-Federmutter - M6 x 1 x 30.
  Quantity
  4
• Part Number
  83990583
  Description
  Sicherungsscheibe.
  Quantity
  4
• Part Number
  47728710
  Description
  DICHTSTREIFEN.
  Quantity
  1
• Part Number
  87105841
  Description
  HALTERUNG.
  Quantity
  2
• Part Number
  87107420
  Description
  TÜLLE.
  Quantity
  1
• Part Number
  43253
  Description
  SCHRAUBE.
  Quantity
  6
• Part Number
  87664050
  Description
  UNTERLEGSCHEIBE.
  Quantity
  2
• Part Number
  84146279
  Description
  HEBELSCHALTER.
  Quantity
  1
• Part Number
  84146280
  Description
  HEBELSCHALTER.
  Quantity
  1
• Part Number
  84150190
  Description
  AUFKLEBER.
  Quantity
  1
• Part Number
  87312626
  Description
  Relais.
  Quantity
  1
• Part Number
  84169304
  Description
  DREHSCHALTER.
  Quantity
  1
• Part Number
  84169306
  Description
  POTENTIOMETER.
  Quantity
  1
• Part Number
  84169308
  Description
  PLATTE.
  Quantity
  1
• Part Number
  47821526
  Description
  Horizontal-Empfänger-Trockner - 202 mm L.
  Quantity
  1
• Part Number
  84191331
  Description
  KLIMAANLAGENSCHLAUCH.
  Quantity
  1
• Part Number
  84191332
  Description
  KLIMAANLAGENSCHLAUCH.
  Quantity
  1
• Part Number
  84591180
  Description
  PARAFUSO ALLENA FLAN.
  Quantity
  2
• Part Number
  8500795
  Description
  Compressor A/C com polia.
  Quantity
  1
• Part Number
  8500878
  Description
  CONDENSADOR.
  Quantity
  1
• Part Number
  8501022
  Description
  PROTEÇÃO.
  Quantity
  1
• Part Number
  47919558
  Description
  Anilha de pressão.
  Quantity
  4
• Part Number
  87397416
  Description
  Correia politrapezoidal do AC - 1725 mm C x 95 mm L.
  Quantity
  1
• Part Number
  76082265
  Description
  BLOCO.
  Quantity
  2
• Part Number
  76082618
  Description
  BLOCO.
  Quantity
  1
• Part Number
  895-30100
  Description
  ARRUELA PLANA.
  Quantity
  2
• Part Number
  86505530
  Description
  PARAFUSO.
  Quantity
  4
• Part Number
  51695696
  Description
  EVAPORADOR.
  Quantity
  1
• Part Number
  84595898
  Description
  INSTRUÇÃO.
  Quantity
  1
