Ref.
Qty
Part #
Alts
Description
-
11FINAL DRIVE; Drive Assy., Final;BSN 559687
-
11GEARBOX; Drive Assy.,, Final;Left & Right Final Drives use all the same components. The only difference is the position of the Magnetic Pipe Plug & the Vent Plug Assy., Ref. 24;ASN 559688
-
1A1FLANGE; Axle, For 742153 Final Drive;BSN 559687
-
1A1FLANGE; Axle, For 84031621 Final Drive;ASN 559688
-
21SEAL 198.3mm ID x 230mm OD x 13mm Thk; 9.06'' OD, For 84031621 Final Drive;ASN 559688
-
21SEAL; BSN 559688
-
31ROLLER BEARING 104.78mm ID x 48.21mm W; Bearing, Cone, 4.125'' (104.77mm) ID
-
41BEARING CUP 181mm OD x 38.3mm W; Bearing, Tapered, Cup, 7-1/8'' OD x 1-1/2'' Wide
-
51GEAR; 111T
-
61SPACER 105.01mm ID x 114.81mm OD x 39.22mm L; 1-35/64'' (39.2mm) Long
-
71SPACER M84 ID x 98.5mm OD x 4.6mm H; 3-7/8'' (98.3mm) OD x 3/16'' (4.75mm) Long
-
81BEARING ASSY 139.99mm OD x 28.57mm W; Bearing, Tapered, Cup, 5-1/2'' OD x 1-1/8'' Wide
-
91BEARING, ROLLER, CYL 82.55mm ID x 36.17mm W; Cone, Bearing, 3-1/4'' (82.56mm) ID
-
101WASHER Special, 17mm ID x 95mm OD x 14mm Thk; Plate, Retainer
-
113BOLT Hex, M16 x 2 x 35mm, Cl 8.8; Screw, Cap, HH, CL 8.8, M16 x 2 x 35
-
ARNOT SERVICED; Wire, Lock, 13 Gauge
-
121COVER 153.5mm OD x 42.1mm W; Cap, Hub, 5.665'' (143.9mm) Bore
-
131BEARING COVER; Cap, Bearing, 4-1/4'' (108mm) Bolt Circle
-
4BOLT Hex, M8 x 1.25 x 50mm, Cl 8.8;
-
4BELLEVILLE WASHER 10mm ID x 22mm OD x 1.6mm Thk; WASHER, BELLEVILLE, M10
-
14ARSHIM 89.7mm ID x 108mm OD x 0.05mm Thk;
-
14ARSHIM 89.7mm ID x 108mm OD x 0.2mm Thk;
-
14ARSHIM 89.7mm ID x 108mm OD x 0.5mm Thk;
-
151HOUSING; for 742153;BSN 559687
-
151HOUSING; for 84031621;ASN 559688
-
162DOWEL 29.92mm OD x 35.1mm L; Dowel
-
171GASKET 2mm Thk;
-
181COVER; 15/64'' (584mm) Long
-
18BOLT Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd; Hex, M10 x 20, 8.8, Full Thd
-
18WASHER 11mm ID x 35mm OD x 3mm Thk; Special, Hardened
-
18BELLEVILLE WASHER 10mm ID x 22mm OD x 1.6mm Thk; WASHER, BELLEVILLE, M10
-
192CUP 85.72mm OD x 30.16mm W; Bearing, Tapered Cup, 3-1/2'' OD x 15/16'' Wide
-
202BEARING, ROLLER, CYL 41.25mm ID x 30.16mm W; Bearing, Tapered Cone, 15/8'' ID x 1-7/8'' Wide
-
211SHAFT; Gear, Pinion, 11T
-
221SEAL 38.1mm ID x 57.26mm OD x 7.92mm Thk; Oil
-
231BEARING COVER; Cap, Bearing, 4-1/4'' (108mm) Bolt Circle
-
4BOLT Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd;
-
4BELLEVILLE WASHER 10mm ID x 22mm OD x 1.6mm Thk; WASHER, BELLEVILLE, M10
-
241BREATHER; Plug Assy., 24mm, Vent
-
25ARSHIM 45mm ID x 75mm OD x 0.05mm Thk;
-
25ARSHIM 45mm ID x 75mm OD x 0.2mm Thk;
-
25ARSHIM 45mm ID x 75mm OD x 0.5mm Thk;
-
263PIPE PLUG Sq Hd, 1/8''-27, NTPF; Plug, Pipe, 1/8''-27
-
27ARGASKET 0.9mm Thk; Shim
-
281O-RING 0.139'' Thk x 3.109'' ID, -235, Cl 5, 75 Duro; 3.109'' ID x .139'' Thk
-
292SEALING RING 24.3mm ID x 28.9mm OD x 2mm Thk; Gasket, Copper, M24 ID x 28.9 OD
-
302PLUG M18 X 1.5; Pipe, 1/2''
-
312GASKET; Washer, Sealing
-
321DRAIN PLUG M24 x 1.5; PLUG, DRAIN, M24 x 1.5
-
331PLUG M24 x 1.5; Magnetic Pipe
Select All
![]()
![]()
Ref.
1Qty
1Availability
Part #
742153Description
FINAL DRIVE; Drive Assy., Final;BSN 559687Img
Alts
Ref.
1Qty
1Availability
Part #
84031621Description
GEARBOX; Drive Assy.,, Final;Left & Right Final Drives use all the same components. The only difference is the position of the Magnetic Pipe Plug & the Vent Plug Assy., Ref. 24;ASN 559688Img
Alts
Ref.
1AQty
1Availability
Part #
9510174Description
FLANGE; Axle, For 742153 Final Drive;BSN 559687Img
Alts
Ref.
1AQty
1Availability
Part #
84031619Description
FLANGE; Axle, For 84031621 Final Drive;ASN 559688Img
Alts
Ref.
2Qty
1Availability
Part #
9832264Description
SEAL 198.3mm ID x 230mm OD x 13mm Thk; 9.06'' OD, For 84031621 Final Drive;ASN 559688Img
Alts
Ref.
3Qty
1Availability
Part #
765849Description
ROLLER BEARING 104.78mm ID x 48.21mm W; Bearing, Cone, 4.125'' (104.77mm) IDImg
Alts
Ref.
4Qty
1Availability
Part #
86516463Description
BEARING CUP 181mm OD x 38.3mm W; Bearing, Tapered, Cup, 7-1/8'' OD x 1-1/2'' WideImg
Alts
Ref.
6Qty
1Availability
Part #
84814999Description
SPACER 105.01mm ID x 114.81mm OD x 39.22mm L; 1-35/64'' (39.2mm) LongImg
Alts
Ref.
7Qty
1Availability
Part #
613200Description
SPACER M84 ID x 98.5mm OD x 4.6mm H; 3-7/8'' (98.3mm) OD x 3/16'' (4.75mm) LongImg
Alts
Ref.
8Qty
1Availability
Part #
60751Description
BEARING ASSY 139.99mm OD x 28.57mm W; Bearing, Tapered, Cup, 5-1/2'' OD x 1-1/8'' WideImg
Alts
Ref.
9Qty
1Availability
Part #
612200Description
BEARING, ROLLER, CYL 82.55mm ID x 36.17mm W; Cone, Bearing, 3-1/4'' (82.56mm) IDImg
Alts
Ref.
10Qty
1Availability
Part #
382503Description
WASHER Special, 17mm ID x 95mm OD x 14mm Thk; Plate, RetainerImg
Alts
Ref.
11Qty
3Availability
Part #
398885Description
BOLT Hex, M16 x 2 x 35mm, Cl 8.8; Screw, Cap, HH, CL 8.8, M16 x 2 x 35Img
Alts
Ref.
12Qty
1Availability
Part #
613201Description
COVER 153.5mm OD x 42.1mm W; Cap, Hub, 5.665'' (143.9mm) BoreImg
Alts
Ref.
13Qty
1Availability
Part #
613212Description
BEARING COVER; Cap, Bearing, 4-1/4'' (108mm) Bolt CircleImg
Alts
Ref.
Qty
4Availability
Part #
140045Description
BELLEVILLE WASHER 10mm ID x 22mm OD x 1.6mm Thk; WASHER, BELLEVILLE, M10Img
Alts
Ref.
14Qty
ARAvailability
Part #
382948Description
SHIM 89.7mm ID x 108mm OD x 0.05mm Thk;Img
Alts
Ref.
14Qty
ARAvailability
Part #
382949Description
SHIM 89.7mm ID x 108mm OD x 0.2mm Thk;Img
Alts
Ref.
14Qty
ARAvailability
Part #
382950Description
SHIM 89.7mm ID x 108mm OD x 0.5mm Thk;Img
Alts
Ref.
Qty
18Availability
Part #
43138Description
BOLT Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd; Hex, M10 x 20, 8.8, Full ThdImg
Alts
Ref.
Qty
18Availability
Part #
743794Description
WASHER 11mm ID x 35mm OD x 3mm Thk; Special, HardenedImg
Alts
Ref.
Qty
18Availability
Part #
140045Description
BELLEVILLE WASHER 10mm ID x 22mm OD x 1.6mm Thk; WASHER, BELLEVILLE, M10Img
Alts
Ref.
19Qty
2Availability
Part #
18428Description
CUP 85.72mm OD x 30.16mm W; Bearing, Tapered Cup, 3-1/2'' OD x 15/16'' WideImg
Alts
Ref.
20Qty
2Availability
Part #
18427Description
BEARING, ROLLER, CYL 41.25mm ID x 30.16mm W; Bearing, Tapered Cone, 15/8'' ID x 1-7/8'' WideImg
Alts
Ref.
22Qty
1Availability
Part #
66807Description
SEAL 38.1mm ID x 57.26mm OD x 7.92mm Thk; OilImg
Alts
Ref.
23Qty
1Availability
Part #
754516Description
BEARING COVER; Cap, Bearing, 4-1/4'' (108mm) Bolt CircleImg
Alts
Ref.
Qty
4Availability
Part #
43140Description
BOLT Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd;Img
Alts
Ref.
Qty
4Availability
Part #
140045Description
BELLEVILLE WASHER 10mm ID x 22mm OD x 1.6mm Thk; WASHER, BELLEVILLE, M10Img
Alts
Ref.
26Qty
3Availability
Part #
86539484Description
PIPE PLUG Sq Hd, 1/8''-27, NTPF; Plug, Pipe, 1/8''-27Img
Alts
Ref.
28Qty
1Availability
Part #
913107Description
O-RING 0.139'' Thk x 3.109'' ID, -235, Cl 5, 75 Duro; 3.109'' ID x .139'' ThkImg
Alts
Ref.
29Qty
2Availability
Part #
220025Description
SEALING RING 24.3mm ID x 28.9mm OD x 2mm Thk; Gasket, Copper, M24 ID x 28.9 ODImg
Alts
Ref.
32Qty
1Availability
Part #
150006Description
DRAIN PLUG M24 x 1.5; PLUG, DRAIN, M24 x 1.5Img
Alts
