PART LIST
Clear callout
Select All
Ref.
Qty
Part #
Alts
Description
-
11ARM; Torque
-
21INSTRUCTION; Hyd Motor, See Fig. 35.560.01, Ref 1
-
31PROTECTION PLATE; Right Hand Motor
-
41COUPLING; Flexible
-
61SPACER;
-
72PIN;
-
81INSTRUCTION; See Fig. 35.560.01, Ref. 20
-
92PILLOW BLOCK;
-
102GUARD; Anti Wrap
-
112SPACER; Head
-
121ROLLER; Driver
-
131KEY 5/16'' Sq x 1 3/8'', Par;
-
141PROTECTION PLATE; Shaft
-
151SPACER;
-
161ARM; Male Torque
-
171WOODRUFF KEY #15, 1/4'' x 1'', HT;
-
188BOLT Hex, 3/8'' - 16 x 1'', Gr 5;
-
194BOLT Hex, 1/2'' - 13 x 4'', Gr 5;
-
204HEX SOC SCREW 1/4'' - 28 x 3/4'';
-
212WASHER 0.44'' ID x 1'' OD x 0.08'' Thk;
-
224WASHER 0.56'' ID x 1.38'' OD x 0.11'' Thk;
-
238LOCK WASHER 3/8 0.381 CST ZND;
-
244LOCK WASHER 1/20.507 CST ZND;
-
252NUT 3/8'' - 16, Gr 5;
-
264NUT 1/2''-13, G5;
-
272COTTER PIN 3/16'' x 2'';
-
281LINCH PIN 6.35mm OD;
Select All
Ref.
2Qty
1Availability
Part #
REFDescription
INSTRUCTION; Hyd Motor, See Fig. 35.560.01, Ref 1Img
Alts
Ref.
21Qty
2Availability
Part #
80702Description
WASHER 0.44'' ID x 1'' OD x 0.08'' Thk;Img
Alts
Ref.
22Qty
4Availability
Part #
80700Description
WASHER 0.56'' ID x 1.38'' OD x 0.11'' Thk;Img
Alts
