11TRANSMISSION; 8.5C Yoke, 16 SPD
-
11REMAN-TRANSMISSION REMAN-TRANS With Reg. Valve 385957A1 (old valve); 8.5C Yoke, 16 SPD
-
11CORE-TRANSMISSION REMAN-TRANS With Reg. Valve 385957A1 (old valve); 8.5C Yoke, 16 SPD
-
11TRANSMISSION; Closed Loop PS3 - 8C
-
11TRANSMISSION; Closed Loop PS3 - 8.5C
-
21HOUSING; Front;REMAN TRANSMISSION Available - P/N 87627458R Before S/N JEE0104001, P/N 87627456R for S/N JEE0104001 & After
-
31HOUSING; Rear
-
4ARSHIM 0.1mm Thk; (0.004'')
-
4ARSHIM 0.3mm Thk; (0.012'')
-
4ARSHIM 0.7mm Thk; 0.50 mm (0.020in)
-
51O-RING 43.8mm ID x 5.33mm Thk, NBR;
-
61COUPLING FLANGE; 8.5C, Input;With 500 Series Axles
-
61COUPLING FLANGE; 8C, Input;With 400 Series Axles
-
71OIL SEAL;
-
81RETAINER;
-
91GASKET;
-
10ARSHIM 0.5mm Thk; (0.020'')
-
10ARSHIM 0.3mm Thk; (0.012'')
-
10ARSHIM 0.15mm Thk; (0.006'')
-
10ARSHIM 0.1mm Thk; (0.004'')
-
111ADAPTER;
-
121SNAP RING M28, Int;
-
131COUPLING;
-
141SNAP RING; RING SNAP
-
151RETAINER; Second Shaft
-
161GASKET; Second Shaft
-
171PLATE; (SN Break) Up to JEE0104001
-
171PLATE; (SN Break) From JEE0104001
-
181GASKET; (SN Break) Up to JEE0104001
-
181GASKET; (SN Break) From JEE0104001
-
191PLATE; (SN Break) Up to JEE0104001
-
191PLATE; (SN Break) From JEE0104001
-
201GASKET; Third Shaft
-
211O-RING;
-
222PLUG;
-
231RETAINER; Third Shaft
-
24ARSHIM 0.3mm Thk; (0.012'')
-
24ARSHIM 0.5mm Thk; (0.020'')
-
24ARSHIM 0.15mm Thk; (0.006'')
-
24ARSHIM 0.1mm Thk; (0.004'')
-
25ARVALVE; Solenoid, Pulse With Modulation, See Figure 06-51
-
261RETAINER; Clutch
-
271GASKET;
-
28ARSHIM 0.15mm Thk; (0.006'')
-
28ARSHIM 0.1mm Thk; (0.004'')
-
28ARSHIM 0.3mm Thk; (0.012'')
-
28ARSHIM 0.5mm Thk; (0.020'')
-
28ARSHIM 0.7mm Thk; (0.028'')
-
294BOLT Hex, M12 x 1.25 x 25mm, Cl 8.8, Full Thd;
-
301WASHER 5.5mm ID x 10mm OD x 1mm Thk;
-
311O-RING; 0.70 mm
-
321FILTER; PWM
-
332RETAINING PLATE;
-
34ARSHIM 0.1mm Thk; (0.004'')
-
34ARSHIM 0.3mm Thk; (0.012'')
-
352O-RING;
-
361COUPLING FLANGE; 8.5C, Output;With 500 Series Axles
-
361COUPLING FLANGE; 8C, Output;With 400 Series Axles
-
371RING;
-
382OIL SEAL;
-
391RETAINER; Output
-
401GASKET;
-
411COUPLING FLANGE; 8.5C, Output;With 500 Series Axles
-
411COUPLING FLANGE; 8C, Output;With 400 Series Axles
-
421COVER; Power Takeoff
-
432HEX PLUG M42 x 2 x 34mm L, ORB; Inc. 44
-
441O-RING 38.6mm ID x 2.9mm Thk, HNBR;
-
451PLUG, DRAIN; M42 orb x 2, Inc. 46
-
461O-RING 38.6mm ID x 2.9mm Thk, HNBR;
-
4715HEX PLUG M14 x 1.5 x 19.5mm L, ORB; Incl. 48
-
481O-RING 11.3mm ID x 2.2mm Thk, HNBR;
-
492BOLT; M14 x 35, CL8.8
-
5024BOLT Hex, M10 x 1.25 x 35mm, Cl 8.8, Full Thd;
-
516LOCK WASHER M10;
-
522BOLT Hex, M10 x 1.25 x 25mm, Cl 8.8, Full Thd;
-
534BOLT Hex, M10 x 1.25 x 60mm, Cl 8.8;
-
542BOLT Hex, M8 x 1.25 x 40mm, Cl 8.8, Full Thd;
-
556BOLT Hex, M12 x 1.25 x 35mm, Cl 10.9, Full Thd;
-
561DUST CAP;
-
571NOT SOLD SEPARAT; Fitting
-
581O-RING 11.3mm ID x 2.2mm Thk, HNBR;
-
592BOLT;
-
601RETAINING PLATE;
-
1DIAGNOSTIC COUPLER; Diagnostic, Inc. 56 - 58
-
1GASKET KIT; Transmission Repair, Inc. 5, 7, 9, 16, 18, 20, 21, 27, 35, 38, 40, Also See Figures 06-37 - 06-50
-
1GASKET KIT; Transmission Repair, Inc. 9, 16, 18, 20, 27, 40, Also See Figures 06-37, 06-49, 06-50; (SN Break) Up to JEE0104001
-
1GASKET KIT; Transmission Repair, Inc. 9, 16, 18, 20, 27, 40, Also See Figures 06-37, 06-49, 06-50; (SN Break) From JEE0104001
