Ref.
Qty
Part #
Alts
Description
-
12CAP;
-
24BRAKE DISC; Disc, Steel, See Service Bulletin 12/96-I9
-
32SEPARATOR;
-
44SPACER 13.41mm ID x 25.4mm OD x 20.5mm L;
-
52PLUG; Disc, Friction, See Service Bulletin 5/95-I3
-
62PLUG;
-
71SUPPORT; LH (LH Thread)
-
81SUPPORT; RH (RH Thread)
-
94BOLT Hex, 1/2'' - 13 x 2 1/2'', Gr 8; Screw, Cap, HH, G8, 1/2''-13 x 2-1/2''
-
104WASHER 13.1mm ID x 25.4mm OD x 3.68mm Thk; (1/2'') M13 x 25 x 3.5, HT
-
112BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''
-
122LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
132OIL SEAL; Oil, Lip
-
141SHAFT; Brake, LH
-
151SHAFT; Brake, RH
-
162LEVER; Arm, Brake
-
172BOLT 1/4''-20 x 1-1/4'', Cl 5; HH, G5, 1/4''-20 x 1-1/4''
-
182JAM NUT Jam, 1/4''-20, G2; Jam, G2, 1/4''-20
-
194ROD; Brake, Weld Assy.; (Prod Date) Up to 31-Oct-1997
-
204COTTER PIN 1/8'' x 3/4''; PIN, SPLIT (COTTER), 1/8'' x 3/4''
-
212/4LOCK NUT PREVAILING TORQUE, 3/8'' - 16, Gr C, Directional; Nut, Lock, GC, 3/8''-16
-
222SPRING;
-
231SHAFT; Weld Assy.
-
241ANGLE;
-
252BOLT Hex, 3/8'' - 16 x 3/4'', Gr 5; Screw, Cap, HH, G5, 3/8''-16 x 3/4''
-
262BELLEVILLE WASHER 10mm ID x 22mm OD x 1.6mm Thk; WASHER, BELLEVILLE, M10
-
272NUT 3/8'' - 16, Gr 5; G5, 3/8''-16
-
282BOLT Hex, 3/8'' - 16 x 1 1/4'', Gr 5;
-
291WASHER; Leather
-
302BUSHING 19.07mm ID x 24.69mm OD x 15.88mm L;
-
312SPACER;
-
321LATCH; See Service Bulletin 7/94-I1
-
331HANDLE;
-
341BELLEVILLE WASHER M6 Bolt Size x 14mm OD x 1.3mm Thk; WASHER, BELLEVILLE, M6
-
351SPRING;
-
361HOOK; Hook Weld Assy.
-
371HANDLE GRIP; Grip, Handle
-
382BOLT; J, 3/8''-16 x 5''; (Prod Date) From 01-Nov-1997
-
392CUP; Weld Assy.; (Prod Date) From 01-Nov-1997
-
402ROD; Weld Assy., Brake; (Prod Date) From 01-Nov-1997
-
412SLOTTED PIN 1/8'' OD x 1'' OAL; PIN, SLOTTED, 1/8'' x 1''; (Prod Date) From 01-Nov-1997
-
42-ORDER COMPONENTS; Gearbox, LH & RH, See Figure 06B02
-
43REFSWITCH; Brake (Not Shown)
