05.100.03[01] - FILTERS & CAPACITIES, 2344
TABLE OF CONTENTS
DIAGRAM
PART LIST
Clear callout
Serial Number Window
Build Date
Select All
Ref.
Qty
Part #
Alts
Description
Select All

Select

Ref.

*

Qty

-

Availability

Part #

CNH XHD COOLANT

Description

ANTIFREEZE; Engine Coolant, 9 Gal


Alts

Select

Ref.

1

Qty

-

Availability

Part #

J934430

Description

ENGINE OIL FILTER; If Used


Alts

Select

Ref.

2

Qty

1

Availability

Part #

86998333

Description

AIR FILTER Primary, 172.3mm ID x 332.4mm OD x 555.2mm L, Pleatloc; Engine


Alts

Select

Ref.

*

Qty

-

Availability

Part #

NO. 1 SAE 15W40

Description

OIL; Engine And Filter, 16 QT


Alts

Select

Ref.

2

Qty

1

Availability

Part #

247752A1

Description

CAB FILTER; Air


Alts

Select

Ref.

3

Qty

1

Availability

Part #

120486A2

Description

CAB FILTER; Recirculation


Alts

Select

Ref.

4

Qty

1

Availability

Part #

87784C92

Description

HYDRAULIC OIL FILTER 121.4mm OD x 343.4mm L; Charge Pump


Alts

Select

Ref.

5

Qty

-

Availability

Part #

1329214C1

Description

HYDRAULIC OIL FILTER; Includes Two Elements And Four Seals


Alts

Select

Ref.

*

Qty

-

Availability

Part #

HY-TRAN ULTRA

Description

OIL; Hydraulic, 10-Gal


Alts

Select

Ref.

*

Qty

-

Availability

Part #

HY-TRAN ULTRA

Description

OIL; Transmission, 17-QT


Alts

Select

Ref.

6

Qty

1

Availability

Part #

90-3941T1

Description

SEPARATOR; Fuel Filter


Alts

Select

Ref.

7

Qty

1

Availability

Part #

J931063

Description

FUEL FILTER; Fuel Filter


Alts

Select

Ref.

*

Qty

-

Availability

Part #

135H EP 85W140

Description

OIL; Feeder And Cleaning Fan Gear Case, 2.75-QT


Alts

Select

Ref.

*

Qty

-

Availability

Part #

HY-TRAN ULTRA

Description

OIL; Feeder Reverser Gear Case, 0.5-QT


Alts

Select

Ref.

*

Qty

-

Availability

Part #

HY-TRAN ULTRA

Description

OIL; Final Drive (Ea), 13-QT


Alts

Select

Ref.

*

Qty

-

Availability

Part #

135H EP 85W140

Description

OIL; Lower Unloader Gear Case, 0.94-QT


Alts

Select

Ref.

*

Qty

-

Availability

Part #

HY-TRAN ULTRA

Description

OIL; PTO Housing, 14-QT


Alts

Select

Ref.

*

Qty

-

Availability

Part #

HY-TRAN ULTRA

Description

OIL; Rotor Gear Case, 4-QT


Alts

Select

Ref.

*

Qty

-

Availability

Part #

HY-TRAN ULTRA

Description

OIL; Straw Chopper Gear Case, 3.3-QT


Alts

Select

Ref.

*

Qty

-

Availability

Part #

ZRG012WGC

Description

GREASE; Chassis Lube, Nlgi #2 White Lithium, As Required


Alts
