PART LIST
Clear callout
Select All
Ref.
Qty
Part #
Alts
Description
-
11BRACKET;
-
22HOSE; L=1150 3/8''
-
32QUICK MALE COUPLING 3/8'' BSP;
-
41WASHER; Blue
-
51WASHER; Red
-
62CAP;
-
71GUIDE;
-
84NUT M10; M10
-
94SCREW; M10 x 30 FXB
-
101GUIDE;
-
111SCREW; M8 x 16
-
122HOSE; L=3630 3/8''
-
131PLATE;
-
141BRACKET;
-
152CLAMP;
-
161WASHER 8.40mm ID x 16mm OD x 1.50mm Thk; 8,4 x 16 x 1,5
-
171SCREW; M8 x 70
-
182CLAMP BRACKET;
-
192PROTECTIVE COVER;
-
202QUICK FEMALE COUPLING 1/2''; 1/2''
-
212ADAPTER;
-
222WASHER;
