010 - CUTTERHEAD GEARBOX ASSEMBLY
ÍNDICE
DIAGRAMA
LISTA DE PIEZAS
BORRAR TODO
Ventana Nº de serie
Fecha de producción
Seleccionar todo
Ref.
Ctd
N.º de pieza
Alts
Descripción
Imagen
  • AR
    9621819
    CAJA DE TRANSMISIÓN; Cutterhead Gearbox Assy., Except European Machines, 1900;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 1
    9621819
    CAJA DE TRANSMISIÓN; Cutterhead Gearbox Assy., Except European Machines, 2100;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • AR
    643224
    CAJA DE TRANSMISIÓN; Cutterhead Gearbox Assy., European Machines Only, 1900;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 1
    643224
    CAJA DE TRANSMISIÓN; Cutterhead Gearbox Assy., European Machines Only, 2100;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 1
    1
    612922
    CUBETA DEL COJINETE 2.562'' ID x 6.5'' OD x 1.78125''; Cover, 4.81'' (122mm) OD x 1.39'' (35mm) Bearing Shoulder;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 1
    1
    572456
    COJINETE; 4.13'' (105mm) OD x .25'' (6.35mm) Bearing Shoulder, 2100;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 6
    88011
    PERNO Hex, 3/8'' - 16 x 1 1/4'', Gr 5;
  • 6
    80680
    ARANDELA DE BLOQUEO 3/8 0.381 CST ZND; WASHER, LOCK, 3/8''
  • 2
    1
    710773
    JUNTA DE ACEITE; Seal, Oil
  • 3
    AR
    854170
    SUPLEMENTO .003'' Thk; (.076mm), 4.84'' (123mm) ID .003'' Thk;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 3
    AR
    572801
    SUPLEMENTO .003'' Thk; (.076mm), 4.16'' (106mm) ID, 2100 .003'' Thk;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 3
    AR
    854171
    SUPLEMENTO .010'' Thk; (.254mm), 4.84'' (123mm) ID .010'' Thk;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 3
    AR
    86516693
    SUPLEMENTO; .010'' (.254mm) Thick, 4.16'' (106mm) ID, 2100;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 4
    1
    572267
    CUBETA DEL COJINETE 105mm OD x 29mm W; Cup, Bearing
  • 5
    1
    572268
    COJINETE DE RODILLOS 49.99mm ID x 36mm W; Cone, Bearing
  • 6
    1
    287554
    JUEGO DE ENGRANAJES; Except European Machines, 12T & 38T
  • 6
    1
    610557
    JUEGO DE ENGRANAJES; European Machines Only, 15T & 37T
  • 10
    280438
    PERNO Hex, 1/2 - 20 x 1, Gr 8, Full Thd; Cap, HH, G8, 1/2''-20 x 1''
  • 10
    281038
    ARANDELA DE BLOQUEO 13.46mm ID x 22.86mm OD x 1.14mm Thk; Washer, Lock, Ext T, 1/2''
  • 7
    1
    86536195
    COJINETE Tapered Roller, 28.57mm ID x 68.26mm OD x 22.23mm W; Bearing,Tapered Cup & Cone Assy.
  • 8
    AR
    572794
    SUPLEMENTO .010'' Thk; (.254mm) .010'' Thk
  • 8
    AR
    572795
    SUPLEMENTO .003'' Thk; (.076mm) .003'' Thk
  • 8
    AR
    572796
    SUPLEMENTO .002'' Thk; (.050mm) .002'' Thk
  • 9
    1
    627273
    CAJA DE TRANSMISIÓN; Housing, Gearbox, 4.81'' (122mm) ID Hole, for Cover Ref. 1;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 9
    1
    718857
    ALOJAMIENTO; Gearbox, 4.13'' (103mm), ID Hole, for Cover Ref. 1a, 2100;Please Check Description Carefully Before Ordering. P/N 718857 has been replaced by P/N's 627273,612922, 854170 & 8854171
  • 1
    87569
    BOQUILLA DE LUBRICAC 45 Degree, 1/4'' NPT x 4/5'' L, Drive; Fitting, Lube, 1/4''-28, 45?
  • 10
    1
    572806
    ARANDELA; Special
  • 11
    1
    199954
    CONO DE COJINETE 50mm ID x 21.5mm W; Cone, Bearing
  • 12
    1
    287066
    CUBETA DEL COJINETE 82.58mm OD x 16.51mm W; Cup, Bearing
  • 13
    1
    86516694
    ARANDELA 19.4mm ID x 53.9mm OD x 6.3mm Thk; Special
  • 14
    1
    88886
    TUERCA CON RANURAS 3/4''-16;
  • 1
    80708
    PASADOR 1/8'' x 1 1/2''; Pin, Split
  • 15
    AR
    854173
    SUPLEMENTO .010'' Thk; (.254mm) .010'' Thk
  • 15
    AR
    854172
    SUPLEMENTO .003'' Thk; (.076mm) .003'' Thk
  • 16
    1
    572458
    TAPÓN; Cap
  • 4
    88011
    PERNO Hex, 3/8'' - 16 x 1 1/4'', Gr 5;
  • 4
    80680
    ARANDELA DE BLOQUEO 3/8 0.381 CST ZND; WASHER, LOCK, 3/8''
  • 17
    1
    80775
    TAPÓN DE VACIADO 1/4'' - 18 NPT; Plug, Pipe, Square Hd., 1/4'' NPT
  • 18
    1
    9823249
    RESPIRADERO; Assy.
  • 19
    1
    288279
    CUBO; Ring Gear, 9-5/16'' (236mm) OD, Except European Machines
  • 19
    1
    612924
    CUBO; Ring Gear, 6-15/16'' (176mm) OD, European Machines Only
  • 20
    1
    572809
    SEPARADOR;
  • 21
    1
    572270
    COJINETE DE RODILLOS 2.5005'' ID x 0.869''; Cone, Bearing
  • 22
    1
    163044
    CUBETA DEL COJINETE 110.03mm OD x 18.82mm W; Cup, Bearing
  • 23
    AR
    572791
    SUPLEMENTO .002'' Thk; (.050mm) .002'' Thk
  • 23
    AR
    86516692
    SUPLEMENTO; .003'' (.076mm) Thick
  • 23
    AR
    572793
    SUPLEMENTO .010'' Thk; (.254mm) .010'' Thk
  • 24
    1
    572808
    ARANDELA; Special
  • 25
    1
    86529540
    ANILLO DE RESORTE 4.331'', Int, #433; Ring, Snap, 4.331'', Int, #433
  • 26
    1
    572804
    JUNTA DE ACEITE; Seal, Oil
  • 27
    1
    9621818
    EJE; & Collar Assy.
  • 28
    2
    280304
    BULÓN; Pin, Dowel, 5/8'' x 1-1/4''
  • 29
    1
    718839
    JUNTA;
  • 30
    1
    612639
    REFRIGERADOR DE ACEITE; Cooler, Oil, 5-5/8'' (143mm) Overall Long, 1900;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 30
    1
    608375
    RADIADOR; Cooler, Oil, 8-1/2'' (216mm) Overall Long, 2100
  • 31
    1
    510185
    JUNTA TÓRICA 56.7mm ID x 3.53mm Thk, NBR; 2.234'' ID x .139'' Thk, 1900;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 31
    1
    86977781
    JUNTA TÓRICA 66.3mm ID x 3.53mm Thk, NBR; 2.625'' ID x .135'' Thk, 2100
  • 32
    1
    612641
    JUNTA TÓRICA 2.55'' ID x 2.756'' OD x 0.103''; 2.550'' ID x .103'' Thk, 1900;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 32
    1
    608377
    JUNTA TÓRICA 2.984'' ID x 3.262'' OD x 0.139''; -234, Cl 7, 2.984'' ID x .139'' Thk, 2100
  • 33
    2
    221964
    JUNTA TÓRICA 21.9mm ID x 1.78mm Thk, FKM; .862'' ID x .070'' Thk;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 33
    2
    122056
    JUNTA TÓRICA 17.2mm ID x 1.78mm Thk, NBR; .676'' ID x .070'' Thk, 2100
  • 34
    1
    9616663
    PLACA; 27/32'' (21.4mm) Oil Cooler Holes, Replaces 719582, 1900;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 34
    1
    608376
    PLACA; 23/32'' (18.2mm) Oil Cooler Holes, 2100
  • 2
    87872
    PERNO Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''
  • 4
    87362
    ARANDELA 5/16'' SAE; SAE, 5/16''
  • 2
    80681
    ARANDELA DE BLOQUEO 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
  • 35
    1
    612633
    CAJA DE TRANSMISIÓN; Bottom, Gearbox, for 612639 Cooler, 1900;Two different Gearboxes are used for production. However, the Model 2100 Gearbox Assy. is used to service both the Model 1900 (BSN 440434) & the Model 2100.
  • 35
    1
    608390
    ALOJAMIENTO; Bottom, Gearbox, for 608375 Cooler, 2100
  • 10
    88206
    PERNO Hex, 3/8'' - 16 x 1'', Gr 5;
  • 10
    80680
    ARANDELA DE BLOQUEO 3/8 0.381 CST ZND; Washer, Lock, 3/4''
  • 36
    1
    87628
    CASQUILLO; Pipe, Hex; (SN Break) Between 1/4'' and 3/8''
  • 37
    1
    232480
    UNIDAD EMISORA; Sender, Oil Temperature, Spade Terminal, 225? F or 107? C
  • 37
    1
    86533697
    TERMOSONDA; Sender, Oil Temperature, Screw Terminal, 240? F or 115.5? C
