TABLE OF CONTENTS
DIAGRAM
PART LIST
Clear callout
Select All
Ref.
Qty
Part #
Alts
Description
-
11FRAME; Main Frame Weld Assy., A3
-
1FRAME; Main Frame Weld Assy., A4
-
1FRAME; Main Frame Weld Assy., A6
-
22SUPPORT; Arm Weld Assy.
-
4BOLT Hex, 1/2'' - 13 x 2 1/4'', Gr 5; HH, G5, 1/2''-13 x 2-1/4''
-
32LIFT LINK; Jack Stand Assy., Includes: Ref. 4 Thru 6
-
42PAD; Weld Assy.
-
52JACK SCREW; Jack Screw Weld Assy.
-
2GROOVED PIN 4.76mm OD x 25.4mm L; Pin, Grooved, 3/16'' x 1'', Type A
-
62CHANNEL; Weld Assy.
-
72PIN; Tongue, 1/2'' x 4-1/8''
-
82COTTER PIN 0.148'' OD x 2.75'' OAL, Internal; PIN, SPLIT (COTTER), , Hair Int, 7/32'' x 2.75'' x 0.148''
-
91ANGLE; R.H., 24-3/8'' (645mm) Lg., A3
-
1ANGLE; R.H., 41-5/8'' (1058mm) Lg., A4
-
1ANGLE; R.H., 64-5/8'' (1642mm) Lg., A6
-
1BOLT Hex, 5/16'' - 18 1'', Full Thd, Gr 5;
-
3CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5
-
4WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
4LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
3SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
101SHIELD; L.H., For Harvester Model 892 Only, A3
-
1SHIELD; L.H., For Harvester Model 1900 Only
-
3CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5
-
3CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5
-
6WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
6LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
6SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
112ANGLE; 15'' (381mm) Lg., Except for Harvester Model 892
-
1ANGLE; 21-3/4'' (552mm) Lg., Only on Harvester Model 892, A3
-
3CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5
-
3WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
3LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
3SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
121SHIELD; R.H., For Harvester Model 892 Only, A3
-
1BOLT; R.H., For Harvester Model 1900 Only
-
3CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5
-
3CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5
-
6WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
6LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
6SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
131SHIELD; Weld Assy., R.H., REplaces P/N 610358
-
131SHIELD; Weld Assy., L.H., Replaces P/N 610359, A6
-
3BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''
-
3WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
3LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
141BRACKET; Hinge, A3,A4
-
2BRACKET; HInge, A6
-
2CARRIAGE BOLT Sht Sq Nk, 5/16'' - 18 x 1/2'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 1/2'', G5, Full Thd
-
2LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
2SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
151HOOK; A3,A4
-
2HOOK; A6
-
161FLOOR; L.H., Except on Harvester Model 892
-
2BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''
-
5CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5
-
7WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
7LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
5SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
171SHIELD; R.H.
-
17A1SHIELD; L.H., A6
-
5BOLT Hex, 1/4''-20 x 1/2'', Gr 5; Screw, Cap, HH, G5, 1/4''-20 x 1/2''
-
5LOCK WASHER 1/4''; Washer, Lock, 1/4''
-
5NUT Hex, 1/4 - 20, Gr 5; 1/4''-20, G5
-
182BOLT; Wing, Type A, G2, 5/16''-18 x 3/4'', A3,A4
-
184BOLT; Wing, Type A, G2, 5/16''-18 x 3/4'', A6
-
2WING NUT; Nut, Wing, 3/8''-16, A3, A4
-
4WING NUT; Nut, Wing, 3/8''-16, A6
-
ARCARRIAGE BOLT Short Sq Nk, 3/8'' - 16 x 1'', Gr 5, Full Thd; BOLT, CARRIAGE, Short NK, 3/8''-16 x 1'', G5, Full Thd
-
ARWASHER 0.41'' ID x 0.81'' OD x 0.07'' Thk; SAE, 3/8''
-
ARLOCK WASHER 3/8 0.381 CST ZND; WASHER, LOCK, 3/8''
-
ARWASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
ARLOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
191ANGLE; Weld Assy., A3,A4
-
192ANGLE; Weld Assy., A6
-
1BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''
-
ARLOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
1SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
ARWASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
ARLOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
1ANGLE; Weld Assy., A3,A4
-
2ANGLE; Weld Assy., A6
-
1LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
201FLOOR; L.H., A4,A6
-
2BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4'', A4, A6
-
3CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, , A4, A6 Short NK, 5/16''-18 x 3/4'', G5
-
5WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A4, A6 5/16''
-
5LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
3SERRATED NUT 5/16'' - 18 Gr 5 ZND; A4, A6 Flg, USR, 5/16''-18
-
211FLOOR; R.H., Except on Harvester Model 892, R.H.
-
2BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''
-
3CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5
-
5WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
5LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
3SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
221FLOOR; R.H., A4,A6
-
1FLOOR; Pan, R,G,, A6
-
3BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''
-
3CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5
-
6WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
6LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
3SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
231ANGLE; L.H., 24 3/8'' Long, (645mm), A3
-
1ANGLE BAR; Angle, L.H., 4l 5/8'' Long, (1058mm), A4
-
1ANGLE; L.H., 64 5/8'' Long, (1642mm), A6
-
1BOLT Hex, 5/16'' - 18 1'', Full Thd, Gr 5;
-
3CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5
-
4WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;
-
4LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''
-
3SERRATED NUT 5/16'' - 18 Gr 5 ZND;
-
241SHIELD; Weld Assy., A3,A4
-
1COTTER PIN 3/16'' OD x 1-1/4'' OAL; Pin, Split (Cotter), 3/16'' x 1-1/4'', A3,A4
-
1BOLT; Wing, Type A, G2, 5/16''-18 x 3/4'', A3,A4
-
1WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3, A4 5/16''
-
1LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3, A4 5/16''
-
251BRACKET; Weld Assy., A3,A4
-
2CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, , A3, A4 Short NK, 5/16''-18 x 3/4'', G5
-
2WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3, A4 5/16''
-
2LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3, A4 5/16''
-
2SERRATED NUT 5/16'' - 18 Gr 5 ZND; A3, A4 Flg, USR, 5/16''-18
-
261FLOOR; For Harvester Model 892 Only, A3
-
2BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4'', A3
-
6CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, , A3 Short NK, 5/16''-18 x 1'', G5
-
2WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3 5/16''
-
2LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3 5/16''
-
6SERRATED NUT 5/16'' - 18 Gr 5 ZND; A3 Flg, USR, 5/16''-18
-
271FLOOR; For Harvestor Model 892 Only, A3
-
2BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4'', A3
-
8CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, , A3 Short NK, 5/16''-18 x 1'', G5
-
2WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3 5/16''
-
2LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3 5/16''
-
8SERRATED NUT 5/16'' - 18 Gr 5 ZND; A3 Flg, USR, 5/16''-18
-
2SPACER; 3/16'' (4.7mm) Thick, A3
-
281ARM; Lift Arm Weld Assy., R.H., For Harvester Model 1900, A3
-
1ARM; Lift Arm Weld Assy., L.H., For Harvester Model 1900, A3
-
1ARM; Lift Arm Weld Assy., R.H., For Harvester Model 892, A3
-
1SUPPORT; Lift Arm Weld Assy., L.H., For Harvester Model 892, A3
-
12BOLT Hex, 1/2'' - 13 x 1'', Gr 5; A3 Hex, 1/2''-13 x 1'', G5, Full Thd
-
12WASHER 0.56'' ID x 1.38'' OD x 0.11'' Thk; A4, A3 1/2''
-
292CAM; For Harester Model 892 Only, A3
-
2BOLT Hex, 1/2'' - 13 x 3-1/4'', Gr 5; A3 Hex, 1/2''-13 x 3 1/4'', G5
-
8WASHER 0.56'' ID x 1.38'' OD x 0.11'' Thk; A3 1/2''
-
302ANGLE; 36-13/32'' (925mm) Lg., A4
-
2ANGLE; 59-3/8'' (1508mm) Lg., A6
-
2BOLT Hex, 1/2'' - 13 x 3-1/2'', Gr 5;
-
10CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, , A4, A6 Short NK, 5/16''-18 x 1'', G5
-
10SERRATED NUT 5/16'' - 18 Gr 5 ZND; A4, A6 Flg, USR, 5/16''-18
-
2BOLT Hex, 1/2'' - 13 x 3-1/2'', Gr 5; A3 Hex, 1/2''-13 x 3 1/2'', G5
-
2SPACER; 3/16'' (4.7mm) Thick, A4,A6
-
2NUT 1/2''-13, G5;
-
4NUT 1/2''-13, G5; A3 1/2''-13, G5
-
4NUT 1/2''-13, G5; A3 1/2''-13, G5
-
4LOCK WASHER 1/20.507 CST ZND; WASHER, LOCK, 1/2''
-
12LOCK WASHER 1/20.507 CST ZND; WASHER, LOCK, 1/2''
-
4LOCK WASHER 1/20.507 CST ZND; WASHER, LOCK, 1/2''
Select All
Ref.
Qty
4Availability
Part #
87975Description
BOLT Hex, 1/2'' - 13 x 2 1/4'', Gr 5; HH, G5, 1/2''-13 x 2-1/4''Img
Alts
Ref.
3Qty
2Availability
Part #
602488Description
LIFT LINK; Jack Stand Assy., Includes: Ref. 4 Thru 6Img
Alts
Ref.
Qty
2Availability
Part #
280315Description
GROOVED PIN 4.76mm OD x 25.4mm L; Pin, Grooved, 3/16'' x 1'', Type AImg
Alts
Ref.
8Qty
2Availability
Part #
86627125Description
COTTER PIN 0.148'' OD x 2.75'' OAL, Internal; PIN, SPLIT (COTTER), , Hair Int, 7/32'' x 2.75'' x 0.148''Img
Alts
Ref.
Qty
1Availability
Part #
9635884Description
BOLT Hex, 5/16'' - 18 1'', Full Thd, Gr 5;Img
Alts
Ref.
Qty
3Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
4Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
4Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
10Qty
1Availability
Part #
611153Description
SHIELD; L.H., For Harvester Model 892 Only, A3Img
Alts
Ref.
Qty
1Availability
Part #
701343Description
SHIELD; L.H., For Harvester Model 1900 OnlyImg
Alts
Ref.
Qty
3Availability
Part #
280327Description
CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5Img
Alts
Ref.
Qty
3Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
6Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
6Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
11Qty
2Availability
Part #
701338Description
ANGLE; 15'' (381mm) Lg., Except for Harvester Model 892Img
Alts
Ref.
Qty
1Availability
Part #
289356Description
ANGLE; 21-3/4'' (552mm) Lg., Only on Harvester Model 892, A3Img
Alts
Ref.
Qty
3Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
3Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
3Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
12Qty
1Availability
Part #
611152Description
SHIELD; R.H., For Harvester Model 892 Only, A3Img
Alts
Ref.
Qty
1Availability
Part #
701342Description
BOLT; R.H., For Harvester Model 1900 OnlyImg
Alts
Ref.
Qty
3Availability
Part #
280327Description
CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5Img
Alts
Ref.
Qty
3Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
6Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
6Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
13Qty
1Availability
Part #
687504Description
SHIELD; Weld Assy., R.H., REplaces P/N 610358Img
Alts
Ref.
13Qty
1Availability
Part #
687503Description
SHIELD; Weld Assy., L.H., Replaces P/N 610359, A6Img
Alts
Ref.
Qty
3Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''Img
Alts
Ref.
Qty
3Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
3Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
2Availability
Part #
280616Description
CARRIAGE BOLT Sht Sq Nk, 5/16'' - 18 x 1/2'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 1/2'', G5, Full ThdImg
Alts
Ref.
Qty
2Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
16Qty
1Availability
Part #
713427Description
FLOOR; L.H., Except on Harvester Model 892Img
Alts
Ref.
Qty
2Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''Img
Alts
Ref.
Qty
5Availability
Part #
280327Description
CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5Img
Alts
Ref.
Qty
7Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
7Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
5Availability
Part #
88542Description
BOLT Hex, 1/4''-20 x 1/2'', Gr 5; Screw, Cap, HH, G5, 1/4''-20 x 1/2''Img
Alts
Ref.
18Qty
2Availability
Part #
280689Description
BOLT; Wing, Type A, G2, 5/16''-18 x 3/4'', A3,A4Img
Alts
Ref.
18Qty
4Availability
Part #
280689Description
BOLT; Wing, Type A, G2, 5/16''-18 x 3/4'', A6Img
Alts
Ref.
Qty
ARAvailability
Part #
280503Description
CARRIAGE BOLT Short Sq Nk, 3/8'' - 16 x 1'', Gr 5, Full Thd; BOLT, CARRIAGE, Short NK, 3/8''-16 x 1'', G5, Full ThdImg
Alts
Ref.
Qty
ARAvailability
Part #
87016Description
WASHER 0.41'' ID x 0.81'' OD x 0.07'' Thk; SAE, 3/8''Img
Alts
Ref.
Qty
ARAvailability
Part #
80680Description
LOCK WASHER 3/8 0.381 CST ZND; WASHER, LOCK, 3/8''Img
Alts
Ref.
Qty
ARAvailability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
ARAvailability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
1Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''Img
Alts
Ref.
Qty
ARAvailability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
ARAvailability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
ARAvailability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
1Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
2Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4'', A4, A6Img
Alts
Ref.
Qty
3Availability
Part #
280327Description
CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, , A4, A6 Short NK, 5/16''-18 x 3/4'', G5Img
Alts
Ref.
Qty
5Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A4, A6 5/16''Img
Alts
Ref.
Qty
5Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
3Availability
Part #
145458Description
SERRATED NUT 5/16'' - 18 Gr 5 ZND; A4, A6 Flg, USR, 5/16''-18Img
Alts
Ref.
21Qty
1Availability
Part #
713428Description
FLOOR; R.H., Except on Harvester Model 892, R.H.Img
Alts
Ref.
Qty
2Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''Img
Alts
Ref.
Qty
3Availability
Part #
280327Description
CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5Img
Alts
Ref.
Qty
5Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
5Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
3Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4''Img
Alts
Ref.
Qty
3Availability
Part #
280327Description
CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, Short NK, 5/16''-18 x 3/4'', G5Img
Alts
Ref.
Qty
6Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
6Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
23Qty
1Availability
Part #
611145Description
ANGLE; L.H., 24 3/8'' Long, (645mm), A3Img
Alts
Ref.
Qty
1Availability
Part #
609171Description
ANGLE BAR; Angle, L.H., 4l 5/8'' Long, (1058mm), A4Img
Alts
Ref.
Qty
1Availability
Part #
9635884Description
BOLT Hex, 5/16'' - 18 1'', Full Thd, Gr 5;Img
Alts
Ref.
Qty
3Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
4Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk;Img
Alts
Ref.
Qty
4Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, 5/16''Img
Alts
Ref.
Qty
1Availability
Part #
87398Description
COTTER PIN 3/16'' OD x 1-1/4'' OAL; Pin, Split (Cotter), 3/16'' x 1-1/4'', A3,A4Img
Alts
Ref.
Qty
1Availability
Part #
280689Description
BOLT; Wing, Type A, G2, 5/16''-18 x 3/4'', A3,A4Img
Alts
Ref.
Qty
1Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3, A4 5/16''Img
Alts
Ref.
Qty
1Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3, A4 5/16''Img
Alts
Ref.
Qty
2Availability
Part #
280327Description
CARRIAGE BOLT Sq Nk, 5/16'' - 18 x 3/4'', Gr 5, Full Thd; Bolt, Carriage, , A3, A4 Short NK, 5/16''-18 x 3/4'', G5Img
Alts
Ref.
Qty
2Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3, A4 5/16''Img
Alts
Ref.
Qty
2Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3, A4 5/16''Img
Alts
Ref.
Qty
2Availability
Part #
145458Description
SERRATED NUT 5/16'' - 18 Gr 5 ZND; A3, A4 Flg, USR, 5/16''-18Img
Alts
Ref.
26Qty
1Availability
Part #
611151Description
FLOOR; For Harvester Model 892 Only, A3Img
Alts
Ref.
Qty
2Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4'', A3Img
Alts
Ref.
Qty
6Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, , A3 Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
2Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3 5/16''Img
Alts
Ref.
Qty
2Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3 5/16''Img
Alts
Ref.
Qty
6Availability
Part #
145458Description
SERRATED NUT 5/16'' - 18 Gr 5 ZND; A3 Flg, USR, 5/16''-18Img
Alts
Ref.
27Qty
1Availability
Part #
611155Description
FLOOR; For Harvestor Model 892 Only, A3Img
Alts
Ref.
Qty
2Availability
Part #
87872Description
BOLT Hex, 5/16'' - 18 x 3/4'', Gr 5; Screw, Cap, HH, G5, 5/16''-18 x 3/4'', A3Img
Alts
Ref.
Qty
8Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, , A3 Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
2Availability
Part #
80664Description
WASHER 0.38'' ID x 0.88'' OD x 0.08'' Thk; A3 5/16''Img
Alts
Ref.
Qty
2Availability
Part #
80681Description
LOCK WASHER 5/16'' ID x 19/32'' OD x 1/8'' Thk; Washer, Lock, , A3 5/16''Img
Alts
Ref.
Qty
8Availability
Part #
145458Description
SERRATED NUT 5/16'' - 18 Gr 5 ZND; A3 Flg, USR, 5/16''-18Img
Alts
Ref.
28Qty
1Availability
Part #
610911Description
ARM; Lift Arm Weld Assy., R.H., For Harvester Model 1900, A3Img
Alts
Ref.
Qty
1Availability
Part #
610912Description
ARM; Lift Arm Weld Assy., L.H., For Harvester Model 1900, A3Img
Alts
Ref.
Qty
1Availability
Part #
610913Description
ARM; Lift Arm Weld Assy., R.H., For Harvester Model 892, A3Img
Alts
Ref.
Qty
1Availability
Part #
610914Description
SUPPORT; Lift Arm Weld Assy., L.H., For Harvester Model 892, A3Img
Alts
Ref.
Qty
12Availability
Part #
87909Description
BOLT Hex, 1/2'' - 13 x 1'', Gr 5; A3 Hex, 1/2''-13 x 1'', G5, Full ThdImg
Alts
Ref.
Qty
12Availability
Part #
80700Description
WASHER 0.56'' ID x 1.38'' OD x 0.11'' Thk; A4, A3 1/2''Img
Alts
Ref.
Qty
2Availability
Part #
88043Description
BOLT Hex, 1/2'' - 13 x 3-1/4'', Gr 5; A3 Hex, 1/2''-13 x 3 1/4'', G5Img
Alts
Ref.
Qty
8Availability
Part #
80700Description
WASHER 0.56'' ID x 1.38'' OD x 0.11'' Thk; A3 1/2''Img
Alts
Ref.
Qty
10Availability
Part #
280428Description
CARRIAGE BOLT Short Nk, 5/16'' - 18 x 1'', Gr 5; Bolt, Carriage, , A4, A6 Short NK, 5/16''-18 x 1'', G5Img
Alts
Ref.
Qty
10Availability
Part #
145458Description
SERRATED NUT 5/16'' - 18 Gr 5 ZND; A4, A6 Flg, USR, 5/16''-18Img
Alts
Ref.
Qty
2Availability
Part #
9637417Description
BOLT Hex, 1/2'' - 13 x 3-1/2'', Gr 5; A3 Hex, 1/2''-13 x 3 1/2'', G5Img
Alts
Ref.
Qty
4Availability
Part #
80679Description
LOCK WASHER 1/20.507 CST ZND; WASHER, LOCK, 1/2''Img
Alts
Ref.
Qty
12Availability
Part #
80679Description
LOCK WASHER 1/20.507 CST ZND; WASHER, LOCK, 1/2''Img
Alts
Ref.
Qty
4Availability
Part #
80679Description
LOCK WASHER 1/20.507 CST ZND; WASHER, LOCK, 1/2''Img
Alts
